Screen: 23.5 inches, 1920*1080, 100Hz, Brightness: 230±20Lux
CPU:Intel：Intel：Intel® Core™ i5-12450H
Memory：2*SO-DIMM DDR4 ,Max 64GB 3200MHz
Storage： M.2 2280 SSD (supports PCIe 3.0*4 or SATA modes)128/256/512GB/1TB（optional）
Camera：3.0/5.0/8.0MP（optional）
WIFI：M.2 for WIFI(PCIe+USB & CNVi)（optional）
BT：BT4.2/5.1/5.2（optional）
Adapter：DCφ5.0×2.5mm DC 19V/6.32A（Match based on motherboard power）
System：Windows 10(64bit), Windows 11， Linux（optional）
| System Physical Standard Configuration | ||
| Type | Detail | Descriptions |
| Product Form | Product Form | AIO |
| Size | 542*322mm | |
| Material | plastic | |
| Colour | White/black | |
| Pedestal | ascending and descending+swivel | |
| Weight | / | |
| LCD | Resolution | 1920*1080(60Hz/100Hz)（optional） |
| Aspect ratio | 23.8” 16：9 | |
| Brightness | 230±20 cd/m2 | |
| connector | LVDS | |
| Chipset | Southbridge | A300 |
| CPU | Type | Intel：Intel® Core™ i5-12450H |
| GPU | type | Intel® UHD Graphics for 12th Gen Intel® Processors |
| RAM | SO-DIMM Slot*2 | DDR4 2666MHz 8GB |
| SSD | M.2 Slot *1 | M.2 2280 SATA 512GB |
| Hard disk | support | 1*2.5 inch notebook SATA connector（optional） |
| Camera | support | 3.0 MP（optional） |
| Speaker | Box | 2* built-in 4Ω/2W speakers |
| MIC | support | DMIC*2（optional） |
| TPM | support | TPM 2.0（optional ） |
| Fingerprint | support | NO |
| WIFI | WIFI module | IEEE 802.11a/b/g/n/ac compliant WLAN |
| BT | support | Bluetooth 4.2 |
| Ethernet | support | 1*10/100/1000Mbps |
| DC IN | DC *1 | φ5.0×2.5mm DC 19V/6.32A（Match based on motherboard power） |
| HDMI OUT | HDMI*1 | 1* HDMI 1.4 typeA |
| DP/VGA/COM | DP/VGA/COM*1 | 1* VGA |
| USB | USB-A*6 | 2* USB3.2 Gen2+4*USB2.0 |
| RJ45 | RJ45*1 | 1*RJ45 10/100/1000Mbps |
| Audio OUT | Audio OUT jack*1 | 1*Audio OUT jack |
| MIC IN | MIC IN jack*1 | 1*MIC IN jack |
| USB-C | USB-C*1 | optional |
| SD card | Three in one card reader*1 | NO |
| Headphone Combo jack | Headphone Combo jack*1 | NO |
| Adapter | standard | DCφ5.0×2.5mm DC 19V/6.32A（Match based on motherboard power） |
| Keyboard | standard | optional |
| Mouse | standard | optional |
| OS | OS Support | Windows 10(64bit), Windows 11， Linux |
| office | Yes(optional) | |
